Product Details:
|
| Product Name:: | Stainless Steel Threaded Elbow | Connection Mode：: | Threaded Connection |
|---|---|---|---|
| Characteristic：: | Corrosion And High Pressure Resistance | Material：: | 201、304、316 |
| Usage: | Dairy Food And Beverage Industry | Keyword: | Threaded Pipe Fittings |
| High Light: | 316 90 degree long radius elbow,threaded elbow 90 long radius |
||
Elbows are fittings that change the direction of a run in a run system. According to the angle, there are three kinds of most commonly used: 45 ° and 90 ° 180 °. In addition, according to the needs of the project, there are other abnormal angle elbows such as 60 °. The most commonly used materials for elbows are stainless steel, carbon steel, etc.The connection methods of elbow and pipe are: direct welding, flange connection, hot-melt connection, electric fusion connection, threaded connection, socket connection, etc. According to the production process can be divided into: welding elbow, stamping elbow, push elbow, casting elbow, butt welding elbow, etc. 90 degree elbow manufacturing standards include: GB, ANIS, JIS, BS, DIN, UNI, etc.
Type: long radius elbow, short radius elbow.
a. Long radius elbow refers to the outer diameter of the pipe whose radius of curvature is equal to 1.5 times, that is, r = 1.5D.
b. Short radius elbow means that its radius of curvature is equal to the outer diameter of the pipe, that is, r = 1.0D.
Processing: Pushing, Pressing, Forging, Casting, etc.
Standard:SAME B16.9,ASMEB16.11,MSS PS 43,JIS B2311
Thickness: sch5s, sch10s, sch10, sch20, sch30, sch40s, STD, sch40, sch60, sch80s, XS, sch80, sch100, sch120,etc
Technical data sheet
Long Radius Elbow 90 Degree 316 Stainless Steel Pipe Fittings data sheet as below:
| DN | Outside diameter | 90 degree elbow | ||
| A series | B series | Long radius | Short radius | |
| 15 | 213 | 18 | 38 | - |
| 20 | 26.9 | 25 | 38 | - |
| 25 | 33.7 | 32 | 38 | 25 |
| 32 | 42.4 | 38 | 48 | 32 |
| 40 | 483 | 45 | 57 | 38 |
| 50 | 603 | 57 | 76 | 51 |
| 65 | 76.1(73) | 76 | 95 | 64 |
| 80 | 88.9 | 89 | 114 | 76 |
| 100 | 1143 | 108 | 152 | 2 |
| 125 | 139.7 | 133 | 190 | 127 |
| 150 | 1683 | 159 | 229 | 152 |
| 200 | 219.1 | 219 | 305 | 203 |
| 250 | 273 | 273 | 381 | 254 |
| 300 | 323.9 | 325 | 457 | 305 |
| 350 | 355.6 | 377 | 533 | 356 |
| 400 | 406.4 | 426 | 610 | 406 |
| 450 | 457 | 478 | 686 | 457 |
| 500 | 508 | 529 | 762 | 508 |
| 550 | 559 | - | 838 | 559 |
| 600 | 610 | 630 | 914 | 610 |
| 650 | 660 | - | 991 | 660 |
| 700 | 711 | 720 | 1067 | 711 |
1, Stainless steel threaded elbow refers to the elbow with thread. It is commonly used in water gas pipe, small diameter water pipe, compressed air pipe and low pressure steam pipe, etc.
2, It is connected with the pipe end with thread. The thread can be coated with proper adhesive to ensure sealing.
3, Stainless steel threaded elbow is an environmental protection product instead of traditional carbon steel, aluminum and copper products.
4, The products have long service life, beautiful appearance, acid and alkali resistance and corrosion resistance.
5, It is an ideal choice for high-end communities, hotels and equipment manufacturers.
6, As stainless steel threaded elbow has good comprehensive performance.
7, It is widely used in chemical industry, construction, water supply, drainage, petroleum, light and heavy industry, refrigeration, sanitation, water heating, fire protection, power, aerospace, shipbuilding and other basic projects.
a. Plastic bubble bag package b.Wove bag package c.Pallet d. Customized
Our Long Radius Elbow 90 Degree 316 Stainless Steel Pipe Fittings factory have high ability for production, the delivery time is 45days for small quantity, or if you are hurry for that, we can arrange and meet your shipping date.
