Product Details:
|
| Product Name:: | HDPE Electrofusion Reducer | Material：: | PE100、PE80 |
|---|---|---|---|
| Advantage:: | Firm Connection | Color:: | Black |
| Usage: | Sanitary Construction | Oem: | Acceptable |
| High Light: | PE80 Electrofusion Reducer,black Electrofusion Reducer,Sanitary Electrofusion Reducer |
||
Reducer, also known as reducer, is a kind of chemical pipe fitting, which is mainly used for the connection of two different pipe diameters.At present, there are two main types of reducer popular in the market: concentric reducer and eccentric reducer.The roundness of reducer shall not be greater than 1% of the outer diameter of corresponding end, and the allowable deviation shall be ± 3mm.
The material standard of reducer is SY / t5037, GB / t9711 and GB / t8163.American Standard ASTM A106 / A53 GRB, API 5L, apt5ct, ASTM A105, ASTM a234, ASTM A106.There are also DIN German standards and customized standards required by customers.
At present, the development trend of HDPE pipes and pipe fittings is remarkable, and HDPE electrofusion reducers are widely used.Water supply pipe and gas pipe are the two biggest application markets of HDPE electrofusion reducer.HDPE resin material is polymerized from monomer ethylene. Due to different polymerization conditions such as pressure and temperature, different density of resin can be obtained.
Material:PE100,PE80
Usage: Sanitary Construction
Oem: Acceptable
HDPE electrofusion reducer has good hygienic performance without adding heavy metal salt stabilizer.The material is nontoxic, without scale layer and bacteria, which solves the secondary pollution of urban drinking water.With excellent corrosion resistance, it can resist the corrosion of various chemical media except a few strong oxidants.
Under rated temperature and pressure, HDPE electric fusion reducer can be used safely for more than 50 years. Long service life.The reducer has good toughness, high impact strength, and the weight directly presses the pipe, which will not cause the pipe to break.
The strength of the electrofusion interface of HDPE reducer is higher than that of the pipe body, and the joint will not be disconnected due to the soil movement or live load.The pipeline is light, the welding process is simple, the construction is convenient, and the comprehensive cost of the project is low.
Various chemical water supply pipe electrofusion reducer technical data sheet as below:
| Nominal diameter de/mm |
Pipe outer diameter D1/mma |
Nominal diameter de2/mm |
Pipe outer diameter D2/mma |
Pipe length L/mma |
Insertion depth L1/mma |
Length of melting zone L2/mma |
| 63 | 80 | 50 | 65 | 120 | 50 | 30 |
| 75 | 95 | 50 | 65 | 135 | 55 | 35 |
| 75 | 95 | 63 | 80 | 135 | 55 | 35 |
| 90 | 110 | 63 | 80 | 155 | 65 | 40 |
| 90 | 110 | 75 | 95 | 175 | 65 | 40 |
| 110 | 140 | 75 | 95 | 165 | 75 | 50 |
| 110 | 140 | 90 | 110 | 175 | 75 | 50 |
| 160 | 200 | 90 | 110 | 230 | 75 | 70 |
| 160 | 200 | 110 | 140 | 290 | 95 | 70 |
| 200 | 250 | 110 | 140 | 290 | 105 | 55 |
| 200 | 250 | 160 | 200 | 250 | 105 | 60 |
| 250 | 296 | 160 | 200 | 280 | 120 | 50 |
| 250 | 296 | 200 | 250 | 280 | 120 | 50 |
| 315 | 373 | 200 | 250 | 310 | 140 | 70 |
| 315 | 373 | 250 | 296 | 310 | 140 | 70 |
a. Plastic bubble bag package b.Wove bag package c.Pallet d. Customized.
Our Steel flat factory have high ability for production, the delivery time is 45days for small quantity, or if you are hurry for that, we can arrange and meet your shipping date.
