Product Details:
|
| Product Name:: | HDPE Docking 90 Degree Elbow | Standard:: | GB / ANSI /JIS / DIN |
|---|---|---|---|
| Temperature：: | -60℃-60℃ | Advantage:: | Corrosion Resistance、high Toughness |
| Connection: | Female,Welding | Size: | Customized Size |
| High Light: | water HDPE 90 Degree Elbow,plumbing HDPE 90 Degree Elbow,Female HDPE 90 Degree Elbow |
||
HDPE is a kind of thermoplastic resin material with high crystallinity and non polarity.The appearance of HDPE is milky white and translucent to a certain extent.PE elbow has excellent resistance to most of the chemicals used in life and industry.
HDPE butt fusion elbow has good wear resistance, electrical insulation, toughness and cold resistance.
Standard: GB / ANSI /JIS / DIN
Temperature:-60℃-60℃
Connection: Female,Welding
Good sanitation performance: PE water supply pipe fittings meet the requirements of drinking water sanitation standard GB / t17219.The material is non-toxic. There is no scaling layer and bacteria, which can solve the secondary pollution of urban drinking water.Excellent corrosion resistance: in addition to a small number of strong oxidants, it can resist the corrosion of a variety of chemical media.
No electrochemical corrosion; buried in the soil, not rotten, rust, long-term application without leakage.Long service life: under rated temperature and pressure, PE pipe can be safely used for more than 50 years
Good impact resistance: PE pipe has good toughness, high impact strength, and the weight directly presses over the pipe, which will not cause the pipe to break.Good construction performance: convenient and reliable connection, light weight, convenient installation and maintenance.
Outstanding low temperature resistance: it can be used safely in the temperature range of - 20 ~ 40 ℃, and the low temperature embrittlement point can reach - 70 ℃.
Municipal engineering water supply system, indoor water supply system of buildings, outdoor buried water supply system and residential quarters, etc.Underground water supply system, old pipeline repair, water treatment engineering pipeline system, garden, irrigation and other industrial water pipes.
However, it should be noted that PE pipes cannot be used for hot water pipes.Outdoor laying, where there is sunshine, it is recommended to take shelter measures.
Water Sanitation Butt 90 ° Elbow technical data sheet as below:
| Performance | Company | Requirement | Test parameters | Test method |
| Hydrostatic strength | MPa | GBAT6111-2003 | ||
| Material level | ||||
| PE63 | PE80 | PE100 | ||
| 20°C (100h) Circumferential stress: no fracture, no permeability | 8 | 9 | 12.4 | |
| 80°C (100h) Circumferential stress: no fracture, no permeability | 3.5 | 4.6 | 5.5 | |
| 100°C (100h) Circumferential stress: no fracture, no permeability | 3.2 | 4 | 5 | |
| elongation at break | % | >350 | GBAT8804.3-2003 | |
| Thermal stability (oxidation induction time) |
min | > | 200°C | GBfT17391 1988 |
| Melt mass flow rate | G/10min | MFR change before and after processing < 25% | 190°C, 5kg | GBAT3682-2000 |
| Vertical retraction rate | % | <3 | 110°C | GBfT6671-2001 |
| Withstand voltage performance | MPa | 80 ° C hydrostatic strength (165h), no fracture, no leakage | After the cumulative acceptance of aging energy ≥ 5GJ/m² | GBAT3681 |
| density | G/cm³ | 0.930-0.960 | 23°C | GBAT1033-1986 |
a. Plastic bubble bag package b.Wove bag package c.Pallet d. Customized.
Our Steel flat factory have high ability for production, the delivery time is 25 days for small quantity, or if you are hurry for that, we can arrange and meet your shipping date.
