Product Details:
|
| Product Name: | Stamping Elbow | Material: | Stainless Steel |
|---|---|---|---|
| Connection: | Welding | Technics: | Stamping |
| Type: | Elbow | Size: | 40mm,25mm,200mm |
| Application: | Gas And General Chemical Service | Standard: | DIN,BSP,ANSI |
| Usage: | Convey Water Gas Oil | Packing: | Standard Packing |
| High Light: | 25mm SS Socket Weld Fittings,25mm Elbow Pipe Stainless Steel,40mm Elbow Pipe Stainless Steel |
||
Stamping elbow, In the forming process, the outer arc is in the stretching state, and there is no residual metal in other parts to compensate, so the wall thickness at the outer arc is about 10% thinner. But because it is suitable for single piece production and low cost, the stamping elbow process is mostly used for the production of small batch and thick wall elbow. Stamping elbow is divided into cold stamping and hot stamping. The stamping elbow is mainly composed of connecting parts, which can play an important role in the development of this product. It is suitable for high-rise and high water pressure buildings.
SS Socket Weld Fittings Stamping elbow technical data sheet as below:
| DN | Outside diameter | 90 degree elbow | ||
| A series | B series | Long radius | Short radius | |
| 15 | 213 | 18 | 38 | - |
| 20 | 26.9 | 25 | 38 | - |
| 25 | 33.7 | 32 | 38 | 25 |
| 32 | 42.4 | 38 | 48 | 32 |
| 40 | 483 | 45 | 57 | 38 |
| 50 | 603 | 57 | 76 | 51 |
| 65 | 76.1(73) | 76 | 95 | 64 |
| 80 | 88.9 | 89 | 114 | 76 |
| 100 | 1143 | 108 | 152 | 2 |
| 125 | 139.7 | 133 | 190 | 127 |
| 150 | 1683 | 159 | 229 | 152 |
| 200 | 219.1 | 219 | 305 | 203 |
| 250 | 273 | 273 | 381 | 254 |
| 300 | 323.9 | 325 | 457 | 305 |
| 350 | 355.6 | 377 | 533 | 356 |
| 400 | 406.4 | 426 | 610 | 406 |
| 450 | 457 | 478 | 686 | 457 |
| 500 | 508 | 529 | 762 | 508 |
Specification:
| Grade 1 | Grade 3 | Grade 4 | Grade 6 | Grade 7 | Grade 8 | |||||||
| psi | MPa | psi | MPa | psi | MPa | psi | MPa | psi | MPa | psi | MPa | |
| Tensile strength, min | 55000 | 380 | 65000 | 450 | 60000 | 415 | 60000 | 415 | 65000 | 450 | 100000 | 690 |
| Yield strength, min | 30000 | 205 | 35000 | 240 | 35000 | 240 | 35000 | 240 | 35000 | 240 | 75000 | 515 |
Size:40mm,25mm,200mm
Standard:DIN,BSP,ANSI
Usage:Convey Water Gas Oil
Packing:Standard Packing
Stamping elbow is a fundamental process: first, weld a polygonal cross-section of the ring shell or closed at both ends of the polygonal fan-shaped shell, the internal pressure is applied, under the action of internal pressure, the cross-section gradually turns from polygon to circle, and eventually becomes a circular ring shell. According to the requirements, a circular ring shell can be cut into four 90 degree elbows or six 60 degree elbows or other standard elbows. This process is suitable for making any standard large elbow with the ratio of the middle diameter of the elbow to the inner diameter of the elbow greater than 1.5, which is a good way to make large elbow now.
a. Plastic bubble bag package b.Wove bag package c.Pallet d. Customized.
Our Steel flat factory have high ability for production, the delivery time is 30 days for small quantity, or if you are hurry for that, we can arrange and meet your shipping date.
