Product Details:
|
| Product Name: | Stainless Steel Flange | Standard: | GB / ANSI /JIS / DIN |
|---|---|---|---|
| Technics: | Butt Weld | Material: | Stainless Steel |
| Type: | Flanges | Size: | Full-size |
| High Light: | M12 316 Stainless Steel Flanges,Butt Weld SS316 Flanges,GB Thread SS316 Flanges |
||
Stainless steel flange will not produce corrosion, pitting corrosion, corrosion, is not easy to wear, is one of the building metal materials with higher strength. Because of the good corrosion resistance of stainless steel, it can keep the integrity of engineering design for a long time.
Chrome stainless steel stamping flange also integrates mechanical strength and high extensibility, which is easy to process and manufacture components, and can meet the needs of architects and structural designers. All metals react with oxygen in the atmosphere to form an oxide film on the surface.
Carbon steel, austenitic stainless steel, alloy steel and other high-quality pipes at home and abroad are used for stainless steel butt welding pipe fittings, forged pipe fittings and steel flanges.
Product Name:Stainless steel flange
Standard:GB / ANSI /JIS / DIN
Size:Full-size
Stainless steel flange adopts American Standard ASME (ANSI), German standard DIN, Japanese Standard JIS, Chinese GB / T, JB, SH, Hg and other standards. At the same time, according to the customer's requirements, a variety of difficult, non-standard, extra thick wall series of stainless steel pipe fittings, stainless steel flange and other pipe fittings can be made.
316 stainless steel flanges Stainless steel flange technical data sheet as below:
| Flange | |||||||||||||||||
| DN | Outer diameter of steel pipe | Connection size | Flange thickness | Inside diameter of flange B1 |
Socket | Flange neck | height | Theoretical weight | |||||||||
| Flange outer diameter | Diameter of bolt hole center circle | Bolt hole diameter | Number of bolt holes | thread | B2 | U | N | R | |||||||||
| A | B | A | B | A | B | ||||||||||||
| 10 | 17.2 | 14 | 100 | 70 | 14 | 4 | M12 | 20 | 11.5 | 9 | 18 | 15 | 9 | 34 | 3 | 26 | 1.14 |
| 15 | 21.3 | 18 | 105 | 75 | 14 | 4 | M12 | 20 | 16 | 12 | 22 | 19 | 10 | 38 | 3 | 26 | 1.26 |
| 20 | 26.9 | 25 | 130 | 90 | 18 | 4 | M16 | 20 | 21 | 19 | 27.5 | 26 | 11 | 48 | 4 | 29 | 1.93 |
| 25 | 33.7 | 32 | 140 | 100 | 18 | 4 | M16 | 24 | 26.5 | 26 | 34.5 | 33 | 13 | 52 | 4 | 32 | 2.43 |
| 32 | 42.4 | 38 | 155 | 110 | 22 | 4 | M20 | 24 | 35 | 30 | 43.5 | 39 | 14 | 64 | 5 | 32 | 3.17 |
| 40 | 48.3 | 45 | 170 | 125 | 22 | 4 | M20 | 26 | 41 | 37 | 49.5 | 46 | 16 | 74 | 5 | 34 | 3.88 |
| 50 | 60.3 | 57 | 180 | 135 | 22 | 4 | M20 | 26 | 52 | 49 | 61.5 | 59 | 17 | 86 | 5 | 38 | 4.61 |
a. Plastic bubble bag package b.Wove bag package c.Pallet d. Customized.
Our Steel flat factory have high ability for production, the delivery time is 30 days for small quantity, or if you are hurry for that, we can arrange and meet your shipping date.
