Product Details:
|
| Product Name: | 180 Degree Long Radius Elbow | Standard: | GB / ANSI /JIS / DIN |
|---|---|---|---|
| Technics: | Forged | Connection: | Welding |
| Application: | Connect Pipes | Packing: | Wooden Case |
| High Light: | 180 Degree Long Radius Elbow,DN100 Long Radius Elbow,ANSI Long Radius Elbow |
||
180 degree long radius elbow is a pipe fitting and pipe connector. It is used in the branch pipe of main pipeline. Zhu ah yo uses twists and turns, kneading, pushing, molding, mechanical processing and other cold processing or hot processing methods.
180 degree long radius elbow can be divided into jacking, limiting, forging, casting, etc. It can be divided into national standard, electric standard, water standard, American Standard, German standard, Japanese standard, Russian standard, etc.
Standard:GB / ANSI /JIS / DIN
Application:Connect Pipes
Packing:Wooden Case
The 180 degree long radius elbow can not only save space and reduce weight, but also ensure that the joint will not leak. It has better resistance to intergranular corrosion and has good use characteristics. It shows good use value and role in the use. It is used as an important erosion resistant material in chemical industry, chemical fiber, chemical fertilizer and other industries, and can withstand severe erosion effect, as an important anti-corrosion material.
Industrial Steel Pipe Fittings 180 degree long radius elbow technical data sheet as below:
| Nominal size | Outer diameter of groove | Center to End | |
| DN | I series | II series | 180° elbow |
| 15 | 21.3 | 18 | 38 |
| 20 | 26.9 | 25 | 38 |
| 25 | 33.7 | 32 | 38 |
| 32 | 42.4 | 38 | 48 |
| 40 | 48.3 | 45 | 57 |
| 50 | 60.3 | 57 | 76 |
| 65 | 73 | 76 | 95 |
| 80 | 88.9 | 89 | 114 |
| 90 | 101.6 | 133 | |
| 100 | 114.3 | 108 | 152 |
| 125 | 141.3 | 133 | 190 |
| 150 | 168.3 | 159 | 229 |
| 200 | 219.1 | 219 | 305 |
| 250 | 273 | 273 | 381 |
| 300 | 323.9 | 325 | 457 |
a. Plastic bubble bag package b.Wove bag package c.Pallet d. Customized.
Our Steel flat factory have high ability for production, the delivery time is 25 days for small quantity, or if you are hurry for that, we can arrange and meet your shipping date.
