Product Details:
|
| Product Name:: | Carbon Steel Socket Welding Cross | Technology：: | Hydraulic Bulging And Hot Pressing |
|---|---|---|---|
| Material：: | 10# 20# A3 Q235A | Range：: | DN15-DN1600 |
| Thickness: | STD | Working Pressure: | 1.6Mpa |
| High Light: | 1.6Mpa Socket Weld cross,1.6Mpa Socket Welding cross |
||
The Cross tee can be divided into equal diameter and reducing diameter. The nozzle ends of the equal diameter Cross tee are the same size. The main nozzle size of the reducing Cross tee is the same, and the nozzle size of the branch pipe is smaller than that of the main pipe. A cross is a pipe fitting used at the branch of a pipe. As for the seamless pipe used to make the cross, there are two commonly used processes: hydraulic bulging and hot pressing.
The hydraulic bulging process of the cross can be formed in one time with high production efficiency; the wall thickness of the main pipe and shoulder of the cross is increased. Due to the large tonnage of equipment required for the hydraulic bulging process of seamless cross, it is mainly used for the manufacture of standard wall thickness cross less than dn400. The applicable forming materials are mainly low carbon steel with relatively low cold work hardening tendency.
The inner wall of socket welding cross is often corroded. It should be inspected and treated well to ensure that socket welding cross has good application characteristics and value. After putrefaction, the wall of socket welded cross becomes thinner, showing local pits and pockmarks. It needs to be handled and maintained according to specific methods. Carbon steel cross generally contains a small amount of silicon, manganese, sulfur and phosphorus in addition to carbon. According to its use, carbon steel can be divided into three categories: carbon structural steel, carbon tool steel and free cutting structural steel. Carbon structural steel is divided into building structural steel and machine manufacturing structural steel. Generally speaking, the higher the carbon content in the carbon steel, the higher the hardness and the strength, but the lower the plasticity. The model of carbon steel used for carbon steel cross generally includes: 10#,20#,A3,Q235A,20G,16Mn,ASTM A234,ASTM A105, etc.
Standard: ANSI/ASME B16.11
Material: carbon steel Q235A
Size range: DN 15x15x15-50x50x50
Pressure range: 3000 lb, 6000 lb, 9000 lb
Surface treatment: anti-oil; anti-painting
| Nominal Diameter | Outside Diameter | Center to End | |||||
| D1 | D2 | ||||||
| DN | NPS | Series A | Series B | Series A | Series B | C | M |
| 15x15x15 | 1/2x1/2x1/2 | 21.3 | 18 | 21.3 | 18 | 25 | 25 |
| 15x15x10 | 1/2x1/2x3/8 | 21.3 | 18 | 17.3 | 14 | 25 | 25 |
| 15x15x8 | 1/2x1/2x1/4 | 21.3 | 18 | 13.7 | 10 | 25 | 25 |
| 20x20x20 | 3/4 x 3/4 x 3/4 | 26.9 | 25 | 26.9 | 25 | 29 | 29 |
| 20x20x15 | 3/4 x 3/4 x 1/2 | 26.9 | 25 | 21.3 | 18 | 29 | 29 |
| 20x20x10 | 3/4 x 3/4 x 3/8 | 26.9 | 25 | 17.3 | 14 | 29 | 29 |
| 25x25x25 | 1x1x1 | 33.7 | 32 | 33.7 | 32 | 38 | 38 |
| 25x25x20 | 1x 1x3/4 | 33.7 | 32 | 26.9 | 25 | 38 | 38 |
| 25x25x15 | 1x1x1/2 | 33.7 | 32 | 21.3 | 18 | 38 | 38 |
| 32x32x32 | 1.1/4x1.1/4x1.1/4 | 42.4 | 38 | 42.4 | 38 | 48 | 48 |
| 32x32x25 | 1.1/4x1.1/4x1 | 42.4 | 38 | 33.7 | 32 | 48 | 48 |
| 32x32x20 | 1.1/4x1.1/4x3/4 | 42.4 | 38 | 26.9 | 25 | 48 | 48 |
| 32x32x15 | 1.1/4x1.1/4x1/2 | 42.4 | 38 | 21.3 | 18 | 48 | 48 |
| 40x40x40 | 1.1/2x1.1/2x1.1/2 | 48.3 | 45 | 48.3 | 45 | 57 | 57 |
| 40x40x32 | 1.1/2x1.1/2x1.1/4 | 48.3 | 45 | 42.4 | 38 | 57 | 57 |
| 40x40x25 | 1.1/2x1.1/2x1 | 48.3 | 45 | 33.7 | 32 | 57 | 57 |
| 40x40x20 | 1.1/2x1.1/2x3/4 | 48.3 | 45 | 26.9 | 25 | 57 | 57 |
| 40x40x15 | 1.1/2x1.1/2x1/2 | 48.3 | 45 | 21.3 | 18 | 57 | 57 |
| 50x50x50 | 2x2x2 | 60.3 | 57 | 60.3 | 57 | 64 | 64 |
| 50x50x40 | 2x2x1.1/2 | 60.3 | 57 | 48.3 | 45 | 64 | 60 |
| 50x50x32 | 2x2x1.1/4 | 60.3 | 57 | 42.4 | 38 | 64 | 57 |
| 50x50x25 | 2x2x1 | 60.3 | 57 | 33.7 | 32 | 64 | 51 |
| 50x50x20 | 2x2x3/4 | 60.3 | 57 | 26.9 | 25 | 64 | 44 |
1, The surface treatment of carbon steel cross includes sand blasting, rolling, pickling and polishing. It is suitable for petroleum, chemical, electric power, metallurgy, ship, machinery and other industries.
2, It is widely used in chemical industry, petroleum, electric power, pharmacy, beer, food, dairy beverage, cosmetics and various engineering supporting pipelines all over the world.
a. Plastic bubble bag package b.Wove bag package c.Pallet d. Customized
Our factory have high ability for production, the delivery time is 45days for small quantity, or if you are hurry for that, we can arrange and meet your shipping date.
